VT-8080/2000 NF
JLH
Band saw
Straight cut
Automatic
Structural steels, Stainless steel, Tool steel
Height 800mm/31.5inch Length 800mm/31.5inch
Depth 2000mm/79inch
| Availability: | |
|---|---|
| Specifications | VT-8080/2000NF |
Max. cutting height | 800mm (31.5in) |
Max. cutting length | 800mm (31.5in) |
Cutting depth | 2000mm (79in) |
Supporting surface of front table - Length | 2000mm (79in) |
Supporting surface of front table - Width | 750mm (29.5in) |
| Supporting surface of back table - Length | 2000mm (79in) |
| Supporting surface of backfront table - Width | 750mm (29.5in) |
Max. table load | 800kg (1760lb) |
Length | 5700mm (224in) |
Width incl. chip conveyor | 2650mm (104in) |
Height | 3700mm (146.7in) |
Material support height | 1500mm (59in) |
Total weight | ≈8500kg (18700lb) |
Total connected load | 21.5kW (29.2hp) |
Power of saw motor | 18.5kW (25.16hp) |
Hydraulic motor | 1.5kW (2hp) |
| Cutting speed infinitely variable with | 1-600m/min (0.04-13.7in/min) |
| Saw feed speed | 800-1500m/min (31.5- 59in/min) |
| Rapid motion | 3000mm (119in) |
Dimensions of saw blade | 7820 x 50 x 1.0mm (308 x 1.97 x 0.04in) |
